11.6″ 1920(RGB) ×1080 HD 30 Pin EDP LCD Display

Categories IPS Display, TFT Displays Tags 11.6 inch display, 1920*1080 full hd display, TFT Display, TFT LCD

This 1920×1080 resolution LCD TFT is a standard display with an EDP interface, offering true color and full view. This Liquid Crystal Display is RoHS compliant and can come with or without a touchscreen.

Additional information

Model No.	FW116TFT-V30A02
Module Size	11.6 INCH
Outline Dimension(mm)	261.52±0.2(H)*152.08±0.2(V)
Active Area	256.32(H) ×144.18(V)
Number of Pixel	1920 ×1080
Brightness(cd/m²)	500
Interface	EDP
Viewing Direction	IPS ALL
Operating Temperature	-20°C ~ 70°C
Storage Temperature	-30°C ~ 80°C

Product Details

11.6″ Full Color / High Brightness TFT Module Transmissive / Normal Black with 1920 RGB x 1080

* FW116TFT-V30A02 is a Transmissive type color active matrix liquid crystal display (LCD).

* It is composed of a TFT LCD panel, driver IC, FPC, and backlight.

* This TFT LCD module resolution is 1920×1080.

* Optional with capacitive touch panel and resistive touch screen.

* Backlights with different brightness options from 200 – 1500cd/m2 are available.

* Specific touch panels can be designed & customized.

* RoHS & REACH compliant.

Application: Embedded Systems, automation, GPS, medical equipment, Industrial device, and security equipment, etc

These are just a few of our standard TFT modules; we still have a lot of TFT modules to offer.

If none of these modules meet your requirements in terms of brightness, interface, or connection method, please email us at info@fwdisplays.com
